BF4M1013 Diesel Engine
Well-known factories in China have introduced the production technology of Deutz BF4M1013 diesel engine and achieved mass production. The engines we provide are all processed and produced by Chinese factories. The parts of this engine have also been domestically produced on a large scale, which can greatly reduce the price of this engine.
This engine uses an integrated cylinder head. The number of spare parts is reduced, reducing the engine failure rate. It is easy to repair even if there is a problem.
- Product Details
- Products Description
| BF4M1013EC | BF4M1013FC | |
| Rated Power(kw) | 118 | 129 |
| Rated Speed(rpm) | 2300 | 2300 |
| Max torque/speed(N.m/rpm) | 577/1400 | 577/1400 |
| Aspiration | Turbocharged inter-cooled | Turbocharged inter-cooled |
| No. of cylinders | 4 | 4 |
| Configuration | In-line | In-line |
| Injection system | Mechanical unit pump | Mechanical unit pump |
| Displacement(L) | 4.764 | 4.764 |
| Bore(mm) | 108 | 108 |
| Stroke(mm) | 130 | 130 |
| Compression ratio | 18 | 18 |
| Rotation(looking at flywheel) | Counter clock wise | Counter clock wise |
